規格 |
工作荷重 |
主要尺寸(公厘：mm) |
重量 |
||
|
(英吋：1") |
(噸：T) |
A |
B |
C |
(公斤：kg/個) |
|
1/4 |
0.5 |
11.938 |
7.874 |
24.638 |
0.05 |
|
5/16 |
0.75 |
13.462 |
9.652 |
27.178 |
0.08 |
|
3/8 |
1 |
16.764 |
11.176 |
32.512 |
0.13 |
|
1/2 |
2 |
20.574 |
16.002 |
42.164 |
0.27 |
|
5/8 |
3.25 |
26.924 |
19.05 |
51.816 |
0.57 |
|
3/4 |
4.75 |
31.75 |
22.352 |
60.96 |
1.19 |
|
7/8 |
6.5 |
36.576 |
25.4 |
72.644 |
1.43 |
|
1 |
8.5 |
42.926 |
28.702 |
82.296 |
2.15 |
|
1-1/8 |
9.5 |
45.974 |
31.75 |
91.694 |
3.06 |
|
1-1/4 |
12 |
51.562 |
35.052 |
100.838 |
4.11 |
|
1-3/8 |
13.5 |
57.15 |
38.1 |
112.522 |
5.28 |
|
1-1/2 |
17 |
60.452 |
41.402 |
122.936 |
7.23 |
|
1-3/4 |
25 |
73.152 |
50.8 |
146.812 |
12.13 |
|
2 |
35 |
82.55 |
57.15 |
171.958 |
19.19 |
|
2-1/2 |
55 |
104.902 |
69.85 |
204.978 |
32.27 |
|
3 |
85 |
127 |
82.55 |
217.424 |
42.50 |
